MCX623106AN-CDAT Mellanox ConnectX 6 Dx EN Adapter Card – 100GbE Dual Port
MCX623106AN-CDAT Overview
This high-performance adapter is engineered for data centers and enterprise environments that demand rapid connectivity. Featuring dual 100GbE (Gigabit Ethernet) ports, it significantly boosts data transfer speeds, minimizes latency, and enhances network efficiency for high-demand applications.
3,353.00 AED
MCX623106AN-CDAT Technical Specifications
Mellanox ConnectX 6 Dx EN Adapter Card – 100GbE Dual Port
Brand: Mellanox
Manufacturer: Mellanox
Connector Type: Dual Qsfp56 Ethernet (copper and optical)
Data Rates Supported: Ethernet – 1/10/25/40/50/100 Gb/s
Compatible Ethernet Standards: 100GBASE-CR2, 100GBASE-CR4, 100GBASE-KR4, 100GBASE-SR4, 50GBASE-R2
Typical Power Usage for Passive Cables: 18.7W (PCIe Gen 3.0), 19.52W (PCIe Gen 4.0)
Maximum Power for Passive Cables: 25.28W (PCIe Gen 3.0), 26.64W (PCIe Gen 4.0)
Power Availability Through Qsfp56 Ports: 5W (per port)
Voltage: 3.3V aux
Maximum Current: 100mA
Passive Cable Length: 550 LFM (hot aisle – heatsink to port)
Active 2.5W Cable Length: 700 LFM (hot aisle – heatsink to port)
